Other Information | Deep Access, 6 Channels,up to 200 programs, LCD Display Bonding area: 6" x 6" Throat dept: 5.6" Gross table motion: 5.5" Fine table motion: 0.55" Z Motion system: DC servo/LVDT control Z Travel: 9.1mm Ultrasonic system
- 60 kHz Transducer
- Low power: 1.3W
- High power: 2.5W
Bond time:
- Ball bonding/bumping: 20 to 200ms
- Single point, TAB: 20 to 1000ms
- Bond force: 10 to 160 gr
Wire:
- Gold 0.7 to 3.0 Mil
- Spool: 2"
- Wire feed 90°
- Wire termination: clamp tear
Modes of operation:
- Semi-auto
- Manual Z
- Ball bonding
- Single point TAB
- Ball bumping
- Coining
Ball formation: Negative EFO (N.E.F.O.) Heated 2"x2" work holder Targeting spotlight CE Label
|
